24 Way, 10 Amp, Vertical Rack Mount Power Strips

As low as €0.00 €0.00
In stock

Vertical Rack Mount Power Strips

  • Installs in rear of most 19” EIA server racks
  • Covered switch with neon indicator
  • All hardware included
  • Custom requirements available on request

The following options are available for all units

  • Digital ammeter
  • Custom length of lead to terminating plug
  • Terminating commando plugs - 16/32 amp
  • Custom colours

Call for further information on pricing and lead times

Our extensive range of rack mount power strips (PDU’s) are available in a variety of sizes and options. They will install in any rack or server cabinet that meets EIA standards. PDU’s allow power to be distributed from one easily manageable location into the rack, powered from a UPS or directly from the mains.

There is a selection of terminating plugs on our power strips, along with the options for surge protection and digital ammeters. For specific custom requirements, contact the sales team.

More Information
Cord Length 10 foot
Surge Protection Yes
Surge Suppression This intersects the incoming mains feed across the Live, Neutral and Earth terminals. When a large transient voltage enters the PDU through any one of the terminals, the surge protector attempts to re-route this transient voltage away from the PDU and back down the incoming mains cable. This creates a temporary dead short and moves the brunt of the transient voltage to ground. Surge suppression feature is available in select models.
Receptacles & Plugs IEC C13 (IEC 60320), UK 3-Pin Plug (BS1363), IEC C14 Plug, IEC C20 Plug
Number of Outlets 24 Outlets
Powerstrip Orientation Vertical
Finish Powder Coated Black
Amperage 10A
Tech Notes Vertical, rackmount power strips mount in the rear space of a server cabinet. The internal frames of server cabinets vary so different installation methods must be utilized in some circumstances.
Safety Features Cover over switch; External M5 Earth Stud; Every unit is individually tested and given its own unique serial number for full tractability.
RoHS Compliant No
Assembly Notes Fully assembled
TAA Compliant No
